Waveshare KitiBot 2WD Robot Building Kit for micro: bit (no micro: bit)


R1482

In Stock at Supplier

iKhokhaYocoVisaMastercardAmerican ExpressApple PayInstant EFTEFT
Didn't find what you're looking for?
Take a look at these Similar Products or have a look at these Closely Matched Products
Got questions or need assistance?
Please take a look at our Frequently Asked Questions or Contact Us

Overview

Overview
When KitiBot meets micro:bit, when kids meet programming, the mysterious robotics becomes simple, each interesting idea will come true. By using the graphical programming software, learning programming, and exploring robotics would be as easy as building blocks.
This KitiBot 2WD robot kit uses the BBC micro:bit (NOT included) as the host controller, combined with several functional modules, it is easy for the kids to experience robotic tricks such as: line tracking, obstacle avoiding, ultrasonic ranging, servo operation, Bluetooth remote control, etc.
The KitiBot for micro:bit
1. Onboard connector for plugging in micro:bit
2. Integrates MP2636 Li-ion battery charger with system boost, allows charge the battery even when using
3. Integrates DW01+8205S Li-ion battery protection circuitry: reverse protection, over charge/discharge protection, over current protection, and short circuit protection
4. Integrates TB6612FNG dual H bridge motor driver, high efficiency, low heating
5. Integrates PCA9685 PWM controller, micro:bit IO expansion
6. Integrates TLC1543 AD acquisition chip, allows connect multi analog sensors to the micro:bit
7. Integrates 4x APA102 colorful LEDs, dual-line control, no more conflict between the 8. WS2812B RGB LED and Bluetooth
8. Onboard buzzer to play music

KitiBot for micro:bit Acc Pack

1. Metal box x1
2. KitiBot for micro:bit expansion board x1
3. Line tracking sensor x1
4. Ultrasonic sensor x1
5. KitiBot acrylic head x1
6. Servo x1
7. Servo mounting board x1
8. Ultrasonic adapter x1
9. Motors 2PCS x1
10. Wheels 2PCS x1
11. Omni-direction wheel 2PCS x1
12. PH2.0 20cm 4Pin same side contact cable x1
13. PH2.0 20cm 7Pin same side contact cable x1
14. USB type A plug to micro B plug cable x1
15. Screwdrivers 2PCS x1
16. KitiBot for micro:bit W screws x1

Additional Information

Weight & Size

Weight: 0.494kg
Size: 20cm x 16cm x 10cm

SKU: B0100042462 Category: Tag: Condition: New
