Overview

1. Size: About 87.8 x 40.51 x 2.03mm
2. Weight: About 38g
3. Communication chip: MAX 232
4. Power supply voltage: DC7~DC36V wide voltage universal
5. Communication protocol format: Serial port 232 communication is used, the protocol is very simple, the source program of the single-chip microcomputer is provided, which is convenient for everyone to transplant, and the serial port assistant can be used
6. Send character type:
– A11T relay 1 is turned on, and A10T relay 1 is turned off;
– A21T relay 2 is turned on, and A20T relay 2 is turned off;
– Communication format: (9600, 8, NONE, 1) Baud rate: 9600, 8 bits, no parity, 1 stop bit

Additional Information

Weight & Size

Weight: 0.084kg
Size: 12cm x 8cm x 5cm

SKU: A0100024073 Category: Condition: New
