Overview
Using the latest development of 1/4 inch mega pixel progressive scan CMOS, with enhanced color filters and unique concentrator technology, under a variety of conditions even light environment, can also provide surprising megapixels high-definition, bright image. Applicable to the financial, telecommunications, government, schools, airports, factories, hotels, museums, traffic monitoring, real-time requirements Ultra HD quality places.
1. 1/4 inch line scanning digital and advanced DSP technology.
2. Picture Resolution 720P color CMOS, 1.0 Mega Pixel, 1280 x 720.
3. Optimized H.264 main profile compression algorithm, high compression ratio and high quality image; convenient to realize a transmission of HD images on a narrow band, thus it can save the storage space; support triple bit streams.
4. The most advanced network delivery server technology, easily achieve more user access, Multi-stage user password rights management.
5. Built in Web Server, through the IE browser easy to realize the remote control Settings prison see operation.
6. Support facilities remote security upgrade function.
7. Support DDNS, PPPoE and (UPnP, Support Lan, Wan transport, support onvif 2.3 p2p.
8. Technology of self adaptability to network that it may adjust its video flame rate automatically according to the bandwidth of network.
10. Functions of alarm in video missing, mobile detection or probe, etc. (available to set the regions and sensitivity).
11. Support mobile detection / image shielding / image snapshot.
12. Functions of auto recovery in abnormality and auto reconnection in network breakdown.
Additional Information
Model: SN-IPC-3009FCSW10
Shape: Bullet
Mount Types: Wall bracket
Power Depletion: <6W(Camera)
Power Supply: DC 12V 1.0A
Performance: Motion detection, Night Vision
Interface: RJ45, Video input
Function: Password protection, Intellectual alarm
Network Interface: RJ45 10/100MB Ethernet interface
Wireless Distance: 100m
Mobile Access: Android, iPhone OS
Signal System: PAL, NTSC
Sensor Size: 1/4 inch Progressive Scan
Pixels: 1.0MP
Processor: HS3518+9732
Lens: 4.0mm
Electronic Shutter: 1/25s-1/30,000s
Minimum Illumination: Color: 0.1Lux@F1.6, B/W: 0.08Lux@F1.2
Image Control: Saturation, Brightness, Contrast, Exposure
Video Compression Format: H.264, M-JPEG
Video Bit rate: 0.1M-6Mbps
Infrared Distance: 20-30m
IR LED: 3pcs Gen III IR Array
Environment: Outdoor, Indoor
Operate Temperature: -10 to 55 Degree Celsius
Weight: 0.950kg
Size: 19cm x 10cm x 10cm
