Overview
1) 1/4″ Megapixel CMOS, max image resolution 1280*720@25fps
2) H.264 Main Profile @ level 3.0 coding, real time H.264 dual-stream encoding, resolution, frame rate, bit rate adjustable
3) Support Color/BW mode converting, IR-CUT filter
4) Build in motion detection
5) Built-in Pan/tilt, horizontally 355 degree, vertically 120 degree
6) Support Two-way Audio (Built-in MIC)
7) Support the SD card record,(max32GB) multiple record mode (Timed record, motion detection record, alarm record), and support push the video to your smart phone when motion detected
8) Auto-retrieve function and auto-connection network
9) Including PC surveillance platform and mobile client, easy to remote
10) Integrated ONVIF standard, compatibility with third-party ONVIF platform software
11) Indoor use
12) Mobile view allows you to realize remote view & anywhere & anytime.
13) Support two-dimension bar code (QR code) scanning
14) Specifications:
– Processor: HI3518
– Sensor: 1/4″ Megapixel CMOS
– Lens: 3.6mm lens
– IR LED: 12 IR LEDs, IR distance 8~15m
– Day/Night: IR-CUT
– Min. illumination: 0.1lux; 0 lux with IR on
– Max S/N ratio: 50dB
– Compression: H.264
– Image:
— Main stream: 1280×720@1-25fps, 640×480@1-25fps
— Sub stream: 640×480@1-25fps, 320×240@1-25fps
– Bit Rate: 128~4096kbps, Supports CBR/VBR
– Image Control: Hue, saturation, brightness, contrast, exposure
– Auto image control: AE, AWB
– Compression: G.711-A
– Bit rate: 64kbps/128kbps
– Talk back: Support
– Protocol: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, FTP, UPNP
– Compliance: ONVIF 2.2(1.02 backward compatible)
– PC client and browser: ISS, IE6.0 and above
– Mobile phone: iPhone, iPad, Android
– WIFI Encryption: WAP, WAP2
– LAN: 1 RJ45 10M/100M Ethernet port
– Working temperature: -10℃~ +55℃
– Working humidity: 0% – 90%
– Protection level: IP65 indoor use
– Power supply: DC 5V/2A
– Power consumption: Maximum 6w
Additional Information
Weight: 1.075kg
Size: 19cm x 17cm x 13cm
