2000~6000MHz SMA 1 To 2 Microstrip Power Splitter


R392

In Stock at Supplier

iKhokhaYocoVisaMastercardAmerican ExpressApple PayInstant EFTEFT
Didn't find what you're looking for?
Take a look at these Similar Products or have a look at these Closely Matched Products
Got questions or need assistance?
Please take a look at our Frequently Asked Questions or Contact Us

Overview

1. Impedance: 50 Ohms
2. Phase balance: ±5 degrees
3. Surface treatment: sandblasting guide
4. Port connector: SMA-Female
5. Low insertion loss, low standing wave, high isolation
6. Working temperature: -40~+125 degrees Celsius
7. Frequency range: 2000~6000MHz
8. Amplitude balance: ±0.3dB
9. Isolation: Typ.20dB/Min.19dB
10. Input standing wave: Typ. 1.3/Max.1.45
11. Output standing wave: Typ. 1.20 / Max.1.25
12. Withstand power: 35W for splitter; 2W for combiner
13. Insertion loss: less than or equal to 0.5dB (excluding theoretical loss of 3dB)
14. Dimensions: 36.4×34.6×14.7mm
15. Weight: 50g

Additional Information

Weight & Size

Weight: 0.074kg
Size: 5cm x 5cm x 2cm

SKU: A0100128018 Category: Tag: Condition: New
